Professional Service
Supports & Roof Accessories
Structural Solutions for Mechanical Equipment
A successful mechanical installation requires more than just ductwork. Diaz Sheet Metal provides the critical structural components that secure your system. From custom-pitched roof rails to precision-engineered curb adapters and high-capacity hanging systems, we ensure your equipment is supported with master-grade durability.
Our Services
Engineered Roof Rails
Heavy-duty, fully welded equipment rails fabricated to match your specific roof pitch and structural load requirements.
Custom Curb Adapters
Surgically accurate transitions that allow new RTUs to mate perfectly with existing roof curbs, eliminating the need for roofing modifications.
Structural Hanging
High-capacity Unistrut trapeze systems, seismic-rated cable hangers, and beam clamps engineered for industrial-scale loads.
Equipment Protection
Custom-fabricated burglar bars, aerodynamic rain hoods, and hail guards designed to protect your investment from the elements and intrusion.
Why Choose Diaz Sheet Metal?
Precision pitch-matching ensures level equipment installation
Eliminates costly field modifications and roofing repairs
Welded heavy-gauge construction for maximum longevity
Compatibility with vibration isolation and seismic requirements
Available in Galvanized, Primed Black Iron, and Aluminum
Rapid turnaround for 'Crane Day' emergency replacements
Our Process
1
Field Survey
We verify existing curb dimensions and roof pitch to ensure a 100% accurate fit for adapters.
2
Structural Design
Calculating load distributions and designing supports that meet SMACNA and local building codes.
3
Master Fabrication
Heavy-duty welding and CNC-forming performed by certified industrial fabricators.
4
Coordinated Delivery
Timely delivery to your job site, often synchronized with your crane and rigging schedule.
Frequently Asked Questions
Can you fabricate an adapter for any RTU?▼
Yes. By utilizing our 'Blueprint Fidelity' process, we can engineer a custom transition (curb adapter) that bridges the supply/return configuration of any new unit to any existing roof curb, regardless of age or manufacturer.
Do your roof rails come with wood nailers?▼
Yes. Our standard roof rails include pressure-treated wood nailers, allowing for easy attachment of roofing base flashing and counter-flashing, ensuring a watertight seal.
What gauge do you use for equipment supports?▼
Depending on the unit weight and structural span, we typically utilize 18 GA to 10 GA galvanized steel or heavy-duty structural channel to ensure zero deflection and long-term stability.
Do you offer seismic-rated hanging systems?▼
We supply a variety of hanging solutions, including Gripple® cable systems and structural trapeze hardware, that can be configured to meet specific seismic or high-vibration project requirements.
Ready to Get Started?
Contact us today for a free estimate on your supports & roof accessories project.
